The LiFePo4 prismatic battery cell boasts high safety due to its integrated superior vehicle-level BMS system.
Dual charge method: PV & power grid.
Instant Operation Monitoring: The LCD panel provides a real-time display of operational data and settings. Additionally, you can easily monitor and access this information through our user-friendly mobile app or webpage.
Intelligent programming allows for the setting of priority levels for output from various energy sources.
Compact and lightweight, with speedy installation and configuration. It comes with pre-fabricated connectors, making it plug and play.
| Model | SPESS-3000B | SPESS-5000B |
| Rated Capacity | 60 Ah | 100 Ah |
| Energy | 3.0kWh | 5.0kWh |
| Max. Continuous Charge Current | 60A | 100A |
| Max. Continuous Discharge Current | 80A | 120A |
| Nominal Voltage | 51.2V | |
| Operating Voltage | 40-58.4V | |
| Charging Temperature Range | 0-45℃ | |
| Discharge Temperature Range | -10-60℃ | |
| Designed Life-span | 10 years | |
| Installation form | Wall-mounted | |
| Approx. Dimension W*D*H | 562mm*138* 793.7mmmm | |
| Approx. Weight | 48kg | |
| Power charging | ||
| AC Charging Voltage | (170V~280V)±2%, (90V~280V)±2% | |
| Solar Panel Input Voltage | Voltage ≤145V, Current ≤60A, Max. Power 4200W | |
| AC Output | ||
| Maximum Total output power | 3000W | 5000W |
| Peak output power | 6000W/5s | 10000W/5s |
| Output Voltage | AC220V | |
| Wave type | Pure Sine Wave | |
| Frequency | 50Hz | |
| LCD | ||
| Display size | 41*13mm | |
