Features:
All in one design, integrated inverter and battery system.
Intelligent BMS management system providing comprehensive safe protect.
6kWh high capacity lithium iron phosphate battery. High quality BYD cells.
3kW bidirectional inverter.
Supports UPS (uninterruptible power supply) settings.
With USB charging output ports.
| Model | SP-ESS-6kWh-B1 |
| Electrical Characteristics | |
| Cell Chemistry | LiFePO4 |
| Nominal Voltage | 25.6V |
| Nominal Capacity | 235Ah |
| Rated Energy | 6016Wh |
| Cycle Life | >3000 Cycle @80%DOD,at 25°C |
| Communication | RS485/RS232/CAN |
| Standard Charge | |
| Charge Voltage | 29.2V |
| Standard Charging Current | 100A |
| Rapid Charging Current | 150A |
| Max. Charging Current | 150A |
| Standard Discharge | |
| Discharge Cut-off Voltage | 20A |
| Standard Discharge Current | 100A |
| Max. Continuous Discharge Current | 150A |
| Inverter | |
| AC Output | 230VAC 50/60Hz |
| Rated Power | 3000W |
| MPPT | |
| MAX.PV Array Power | 3000W |
| MPPT Operating Voltage | 90-450VDC |
| MPPT Max Charging Current | 80A |
| UB-A Output | |
| Specification | 5V 3.6A |
| Temperature | |
| Charge Temperature | 0°C~55°C |
| Discharge Temperature | -20°C~65°C |
| Mechanical | |
| Dimensions (W*D*H) | 560*270*670mm |
| Weight | 86.5±0.5Kg |
