Name: 24V 65Ah-150Ah LiFePO4 Lithium Battery Pack for AGV
Brand: Sunpack New Energy
SKU: 24V150Ah
Availability: InStock
Rating: 5 (1 reviews)

24V 65Ah-150Ah LiFePO4 Lithium Battery Pack for AGV

No. 24V150Ah

The Sunpack lithium battery technology used in automated guided vehicles (AGV) offers numerous advantages, including longer operating time, increased lifespan, and faster charging time.

DESCRIPTION

When it comes to powering industrial trucks, mobile robots, and autonomous vehicles, the batteries used must meet specific performance, lifespan, and charging cycle requirements. Opting for high-quality lithium-ion batteries is essential to avoid unnecessary costs. Understanding the correct charging procedures is equally important in maintaining battery functionality and ensuring operational safety.

The versatility of lithium-ion batteries makes them an excellent choice for industrial applications. Thanks to their impressive efficiency, higher energy density, and longer life cycle, they require significantly less maintenance than traditional lead acid batteries. Additionally, operators have the flexibility to charge lithium-ion batteries during short breaks in operation, further enhancing overall productivity.

The Sunpack lithium battery technology used in automated guided vehicles (AGV) offers numerous advantages, including longer operating time, increased lifespan, and faster charging time. Furthermore, the recharge efficiency is unparalleled, meaning that worries about the batteries running out of power can be eliminated.

Features:

Ultra-compact, lightweight — 1/3 smaller than lead-acid batteries, and 2/3 lighter than lead-acid batteries.
Built-in intelligent BMS — with over current, short circuit, over-discharge, overcharge, over voltage, overheat protection functions.
Lightweight Structural Design — LiFePO4 is small and light, saves space, reduces carrying the load, and operates easily.
Perfect Lead Acid Replacement — High efficiency, fast charging, low self-discharge. 100% capacity using, high energy conversion efficiency more efficient operating performance.
Safer And Environmentally Friendly — No acid, no heavy metals, no explosion;corrosion-resistant, heat-resistant, explosion-proof, and waterproof.
features of lithium battery

Technical Parameters:

Model	SPF-24V65Ah	SPF-24V105Ah	SPF-24V150Ah
Nominal Voltage	25.6V	25.6V	25.6V
Nominal Capacity	65Ah	105Ah	150Ah
Energy	1664Wh	2688Wh	3840Wh
Max. Charge Voltage	29.2V
Discharge Cut-off Voltage	20V
Max. Continues Discharge Current	60A	90A	120A
Peak Discharge current	100A	200A	300A
Dimension LWH	400250250 mm	400300300 mm	520268228mm
Weight(approx.)	23.4kg	27.3kg	39.5kg
Communication Protocol	CAN
Housing material	Cold roll Steel case
