It's BMS has necessary functions such as over-charge, over-discharge, over-temperature, over-current, over-voltage and short-circuit protection to guarantee safe, reliable and stable performance
AO, SOC analog output 0-5V, can monitor power
High passive balancing efficiency
LED display
Support high-power charging and discharge to meet various industrial conditions
Wide working temperature range -20~60℃
Small volume
RS485 (IGBT) communication protocol
Product Information
| Category | AGV battery |
|
Nominal Voltage |
25.6V |
|
Nominal Capacity |
60Ah |
|
Energy |
1536Wh |
|
Dimensions |
L433 x W220 x H150mm |
|
Weight |
25Kg (approx) |
|
Internal Resistance |
≤30mohm |
|
Maximum Charging Voltage |
29.2V |
|
Minimum Discharge Voltage |
21.6 |
|
Nominal Discharge Current |
0.5C |
|
Rapid charging Current |
1C |
|
Charging cut-off Voltage |
3.7V/cell |
|
Discharge cut-off voltage |
2.7V/cell |
|
Operation Temperature Range |
-20~60℃ |
|
Storage Temperature |
0~40℃ |
|
Over-Temperature Protection |
Max.: 65℃ |
|
Communication Port |
RS485 |
